Description
| Description: Stainless Steel Friction Stay (GRADE 202) | |||||
|---|---|---|---|---|---|
| Code | Size | Weight Capacity | Bars | Bars Thickness | Openable Degree |
| SS-202-FS-08 | 200mm | 12 Kgs. | 4 | 2mm | 65° |
| SS-202-FS-10 | 250mm | 14 Kgs. | 4 | 2mm | 90° |
| SS-202-FS-12 | 300mm | 16 Kgs. | 4 | 2mm | 90° |
| SS-202-FS-14 | 350mm | 18 Kgs. | 4 | 2mm | 90° |
| SS-202-FS-16 | 400mm | 22 Kgs. | 4 | 2.5mm | 90° |
| SS-202-FS-18 | 450mm | 24 Kgs. | 5 | 3mm | 90° |
| SS-202-FS-20 | 500mm | 26 Kgs. | 5 | 3mm | 65° |
| SS-202-FS-24 | 600mm | 30 Kgs. | 6 | 3mm | 55° |
| SS-202-FS-28 | 700mm | 85 Kgs. | 7 | 3mm | 30° |
| SS-202-FS-30 | 750mm | 100 Kgs. | 7 | 3mm | 30° |
| SS-202-FS-36 | 900mm | 120 Kgs. | 7 | 3mm | 30° |
